| Operating weight |
24540 kg |
| Engine power |
179 kW (240 hp) @ 2000 rpm |
| Max travel speed, fwd |
12 km/h |
| Max travel speed, rev |
13.8 km/h |
| No. of speeds, fwd |
3 |
| No. of speeds, rev |
3 |
| Referenced Shoe width |
560 mm |
| Ground pressure |
76 kPa |
| Blade type |
Straight |
| Blade capacity |
7.8 m³ |
| Depth below ground |
540 mm |
| Lift above ground |
1210 mm |
| Blade angle |
8 ° |
| Blade tilt |
735 mm |
| Transport length |
5500 mm |
| Transport width |
3725 mm |
| Transport height |
3380 mm |
| Model |
Cummins |
| Emission |
Stage I / Stage III |
| Ripper options |
Single-shank ripper；Three-shank ripper |
| Blade options |
Straight; Angle; Semi-U; Full-U; Landfill blade |
