| Engine Power |
36.5 kW (48.9 hp) |
| Operating Weight |
3060 kg |
| Rated Operation Capacity |
795 kg |
| Raise |
3.8 s |
| Dump |
2 s |
| Lower (empty, float down) |
1.9 s |
| Tipping Load |
1590kg |
| Bucket Breakout Force |
24.5 kN |
| Dump Clearance - Full Height |
2220 mm |
| Dump Reach - Full Height |
540 mm |
| Engine Model Perkins |
YCF3050-T307 |
| Emission |
EPA Tier 3 / EU Stage IIIA |
| Cooling System |
13 L |
| Overall Length with Standard Bucket |
3432 mm |
| Overall Width with Standard Bucket |
1630 mm |
| Overall Height to top of Cab |
1940 mm |
| Front Clearance Radius with bucket |
1800 mm |
| Bucket capacity |
0.45 m3 |
