| Engine Power |
50.2 kW (67 hp) @ 2400 rpm |
| Operating Weight |
3100 kg |
| Rated Operation Capacity |
865 kg |
| Raise |
4.2 s |
| Dump |
2.3 s |
| Lower (empty, float down) |
2.1 s |
| Tipping Load |
1730 kg |
| Bucket Breakout Force |
20.4 kN |
| Dump Clearance - Full Height |
2220 mm |
| Dump Reach - Full Height |
540 mm |
| Engine Model |
4TNV98-ZCPLYSC |
| Emission |
EU Stage Ⅲ |
| Cooling System |
13 L |
| Overall Length with Standard Bucket |
3432 mm |
| Overall Width with Standard Bucket |
1630 mm |
| Overall Height to top of Cab |
1940 mm |
| Front Clearance Radius with bucket |
1800 mm |
| Bucket capacity |
0.4 m³ |
