  • Pure electric drive, green environmental protection, better benefits: easily cope with the crisis of rising oil prices, bring long-term sustainable green development to enterprises;
  • Ultra-large capacity battery pack, ultra-long life: fast charging 1.6 hours, normal working conditions of up to 6 to 10 hours, ultra-large capacity lithium iron phosphate battery, safe and durable, ultra-long warranty, enjoy worry-free;
  • Battery package design, safer: integrated battery package design, battery system waterproof, dustproof, safe and reliable;
  • Variable system, more energy saving: effectively avoid energy loss, system energy saving up to 10%.
  • 4280DE
  • 4280DE
  • 4280DE
  • 4280DE
  • 4280DE

Description

Operating Weight
24,000 kg
Standard Moldboard Size
4,270*645*19 mm
Rated Storage Energy
423 kWh
Drawbar Pull
123 kN
Steering Angle
±50°
Front Axle, Wheel Lean Angle
±18°
Front Axle Oscillation
±16°
Length (Standard configuration)
9,980 mm
Overall Width Over Tires
2,860 mm
Cab Height
3,530 mm
Wheelbase
6,700 mm
Middle and Rear Wheel Wheelbase
1,632 mm
Ground Clearance
422 mm
Minimum Turning Radius
7,500 mm
