| Paving Width Range |
3～6/2.5~6/3~5.7 m |
| Maximum Paving Thickness |
350 mm |
| Theoretical Productivity |
1000 t/h |
| Operating Mass |
24 t |
| Model |
ShangChai 4H |
| Rated Power |
118 kW (158 hp / 160 ps) @ 2,000 rpm |
| Paving Speed |
0～18 m/min |
| Traveling Speed |
0～3.5 km/h |
| Hopper Capacity |
12 t |
| Gradability |
≥20% |
| Smoothness |
≤3 mm |
| Tamper Type |
Single Tamper |
| Tamper Frequency |
0～30 Hz |
| Tamper Swing |
5 mm |
| Vibration Frequency |
0-40 Hz |
| Crown Adjustment |
-1~4% |
| Paving Compactness Asphalt Asphalt |
≥90% |
| Paving Compactness Asphalt Stabilized Soil |
≥80% |
| Fuel Tank Capacity |
210 L |
| Length |
6150 mm |
| Width |
3200 mm |
| Height |
3800 mm |
