Paving Width Range
|
3～9 m
|
|
Maximum Paving Thickness
|
500 mm
|
|
Theoretical Productivity
|
1000 t/h
|
|
Operating Mass
|
27.3 t
|
|
Model
|
Cummins B7
|
|
Rated Power
|
169 kW (227 hp / 230 ps) @ 2,000 rpm
|
|
Paving Speed
|
0～18 m/min
|
|
Traveling Speed
|
0～4 km/h
|
|
Hopper Capacity
|
16 t
|
|
Gradability
|
20%
|
|
Smoothness
|
≤2 mm (per 3 meters)
|
|
Tamper Type
|
Single Tamper
|
|
Tamper Frequency
|
0～30 Hz
|
|
Tamper Swing Front
|
-
|
|
Tamper Swing Rear
|
5 mm
|
|
Vibration Frequency
|
0-45 Hz
|
|
Crown Adjustment
|
-1~4%
|
|
Paving Compactness Asphalt Asphalt
|
≥90%
|
|
Paving Compactness Asphalt Stabilized Soil
|
≥80%
|
|
Fuel Tank Capacity
|
350 L
|
|
Length
|
7560 mm |
| Width | 3540 mm |
| Height | 3960 mm |
| Paving Width Range | 2.5～9.5 m |
| Maximum Paving Thickness | 500 mm |
| Theoretical Productivity | 1000 t/h |
| Operating Mass | 22.3 t |
| Model | Cummins B7 |
| Rated Power | 169 kW (227 hp / 230 ps) @ 2,000 rpm |
| Paving Speed | 0～18 m/min |
| Traveling Speed | 0～4 km/h |
| Hopper Capacity | 16 t |
| Gradability | 20% |
| Smoothness | ≤2 mm (per 3 meters) |
| Tamper Type | Double Tamper |
| Tamper Frequency | 0～30 Hz |
| Tamper Swing Front | 0/3/6/8.5/12 mm |
| Tamper Swing Rear | 3/5/6/7/8/9 mm |
| Vibration Frequency | 1-45 Hz |
| Crown Adjustment | -1~4% |
| Paving Compactness Asphalt Asphalt | ≥90% |
| Paving Compactness Asphalt Stabilized Soil | ≥80% |
| Fuel Tank Capacity | 350 L |
| Length | 7350 mm |
| Width |
3540 mm
|
|
Height
|
3960 mm
|
