| Operating Mass |
860 kg |
| Mass On Front Drum |
400 kg |
| Mass On Rear Axle |
460 kg |
| Front Drum Static Linear Load |
52 N/cm |
| Rear Drum Static Linear Load |
60 N/cm |
| Model |
Kaipu 186F1E |
| Emission Regulation |
Stage II |
| Rated Power |
5.3 kW (7.2 hp) @ 3000 rpm |
| Vibration Frequency Low |
55 Hz |
| Nominal Amplitude Low |
0.35 mm |
| Centrifugal Force Low |
30 kN |
| Vibration Frequency High |
55 Hz |
| Nominal Amplitude High |
0.35 mm |
| Centrifugal Force High |
30 kN |
| Drum Diameter |
426 mm |
| Drum Width |
750 mm |
| 1st Maximum Speed, fwd |
0-3.6 km/h |
| Theoretical Gradeability |
30%/35% |
| Min. Ground Clearance |
258 mm |
| Wheelbase |
590 mm |
| Overall Length |
2541 mm |
| Overall Width |
812 mm |
| Overall Height |
1238 mm |
