| Operating Mass |
3360 kg |
| Mass On Front Drum |
1620 kg |
| Mass On Rear Axle |
1740 kg |
| Front Drum Static Linear Load |
135 N/cm |
| Rear Drum Static Linear Load |
145 N/cm |
| Model |
Perkins 403D-15T |
| Emission Regulation |
Stage III |
| Rated Power |
27.3 kW (37 hp) @ 2600 rpm |
| Vibration Frequency |
60 Hz |
| Nominal Amplitude |
0.45 mm |
| Centrifugal Force |
33.5 kN |
| Drum Diameter |
750 mm |
| Drum Width |
1200 mm |
| N Maximum Speed fwd |
10 km/h |
| Theoretical Gradeability |
30% |
| Min. Ground Clearance |
265 mm |
| Wheelbase |
1860 mm |
| Min. Outside Turning Radius |
4050 mm |
| Overall Length |
2610 mm |
| Overall Width |
1310 mm |
| Overall Height |
2645 mm |
