| Operating Weight | 3500 kg |
| Weight on Front Drum | 1750 kg |
| Weight on Rear Drum | 1750 kg |
| Front Drum Static Linear Load | 150 N/cm |
| Rear Drum Static Linear Load | 150 N/cm |
| Model | Perkins 403D-15T |
| Emission Regulation | Stage IIIA |
| Rated Power | 30 kW @ 3,000 rpm |
| Vibration Frequency | 60/45 Hz |
| Nominal Amplitude | 0.35/0.45 mm |
| Centrifugal Force | 30/45 kN |
| Working Width | 1300 mm |
| Maximum Speed Fwd&Rvrs | 10 km/h |
| Theoretical Gradeability | 35% |
| Min. Outside Turning Radius | 4100 mm |
