| Operating Mass | 16000 kg |
| Mass On Vibrating Drum | 8000 kg |
| Mass On Drive Axle | 8000 kg |
| Front Drum Static Linear Load | 368 N/cm |
| Model | Shangchai SC4H140.2G2 |
| Emission Regulation | Stage II |
| Rated Power | 103 kW (140 hp) @ 2000 rpm |
| Vibration Frequency | 30 Hz |
| Nominal Amplitude | 2.0/1.2 mm |
| Centrifugal Force | 300/180 kN |
| Drum Diameter | 1555 mm |
| 1st Maximum Speed, fwd | 2.7 km/h |
| 2nd Maximum Speed, fwd | 5.2 km/h |
| 3rd Maximum Speed, fwd | 11 km/h |
| Theoretical Gradeability | 30% |
| Min. GroundClearance | 450 mm |
| Wheelbase | 2950 mm |
| Min. Outside Turning Radius | 6500 mm |
| Overall Length | 6000 mm |
| Overall Width | 2280 mm |
| Overall Height | 3050 mm |
