| Operating Mass | 26000 kg |
| Mass On Vibrating Drum | 13000 kg |
| Mass On Drive Axle | 13000 kg |
| Front Drum Static Linear Load | 591 N/cm |
| Model | Shangchai SC8DK190.2G3 |
| Emission Regulation | Stage III |
| Rated Power | 140 kW (190 hp) @ 1800 rpm |
| Vibration Frequency | 28/33 Hz |
| Nominal Amplitude | 2.0/1.0 mm |
| Centrifugal Force | 430/300 kN |
| Drum Diameter | 1700 mm |
| 1st Maximum Speed, fwd | 2.7 km/h |
| 2nd Maximum Speed, fwd | 5.2 km/h |
| 3rd Maximum Speed, fwd | 11 km/h |
| Theoretical Gradeability | 30% |
| Min. GroundClearance | 430 mm |
| Wheelbase | 3270 mm |
| Min. Outside Turning Radius | 7000 mm |
| Overall Length | 6658 mm |
| Overall Width | 2440 mm |
| Overall Height | 3150 mm |
