| Operating Mass | 9500 kg |
| Mass On Front Drum | 4900 kg |
| Mass On Rear Axle | 4600 kg |
| Front Drum Static Linear Load | 288 N/cm |
| Rear Drum Static Linear Load | 271 N/cm |
| Model | Cummins QSB3.9-C110 |
| Emission Regulation | Stage III |
| Rated Power | 81 kW ( 109 hp) @ 2200 rpm |
| Vibration Frequency | 45/50 Hz |
| Nominal Amplitude | 0.8/0.4 mm |
| Centrifugal Force | 100/61 kN |
| Drum Diameter | 1200 mm |
| Drum Width | 1700 mm |
| 1st Maximum Speed, fwd | 0-6 km/h |
| 2nd Maximum Speed, fwd | 0-8 km/h |
| 3rd Maximum Speed, fwd | 0-12 km/h |
| Theoretical Gradeability | 40% |
| Min. Ground Clearance | 260 mm |
| Wheelbase | 3585 mm |
| Min. Outside Turning Radius | 6770 mm |
| Overall Length | 4970 mm |
| Overall Width | 1960 mm |
| Overall Height | 3120 mm |
