| Max. Operating Mass | 26000 kg |
| Min. Operating Mass | 15000 kg |
| Single Tire Load | 2364 kg |
| Overlapping of Front & Rear Tire | 45 mm |
| Model | Shangchai SC7H180.2G3 |
| Emission Regulation | Stage III |
| Rated Power | 132 (179 hp) @ 2200 rpm |
| Working Speed | 0～7 km/h |
| Traveling Speed | 0～15 km/h |
| Compacting Width | 2750 mm |
| Theoretical Gradeability | 20% |
| Min. Ground Clearance | 360 mm |
| Wheelbase | 3840 mm |
| Min. Outside Turning Radius | 9000 mm |
| Tire Type | 11.00-20-16PR |
| Tire Numbers | Front 5 Rear 6 |
| Overall Length | 4970 mm |
| Overall Width | 2800 mm |
| Overall Height | 3340 mm |
