| Operating Mass | 18300 kg |
| Mass On Vibrating Drum | 11500 kg |
| Mass On Drive Axle | 6800 kg |
| Front Drum Static Linear Load | 529 N/cm |
| Model | Shangchai SC8D |
| Emission Regulation | Stage II / Stage III |
| Rated Power | 140 kW (190 hp) @ 2200 rpm |
| Vibration Frequency | 28/33 Hz |
| Nominal Amplitude | 2.0/1.2 mm |
| Centrifugal Force | 380/260 kN |
| Drum Diameter | 1600 mm |
| 1st Maximum Speed, fwd | 4 km/h |
| 2nd Maximum Speed, fwd | 5.5 km/h |
| 3rd Maximum Speed, fwd | 6.5 km/h |
| 4th Maximum Speed, fwd | 10.5 km/h |
| Theoretical Gradeability | 45 |
| Min. GroundClearance | 440 mm |
| Wheelbase | 3250 mm |
| Min. Outside Turning Radius | 7000 mm |
| Overall Length | 6450 mm |
| Overall Width | 2300 mm |
| Overall Height | 3050 mm |
