Customized engine is perfectly matched power-train for high efficiency and low fuel consumption.
Programmable hydraulic control suitable for different applications and operating styles.
Robust design of frame structure, wide spread hitch and wear-resistant bucket for maixmum durability.
The new cab of T-series, incorporating enlarged driving space, increased legroom and wider front visibility, offers the operator a comfortable and safe driving experience.
Back tilt engine hood provides larger maintenance space and allows ground-level service, reducing downtime.
| Operating Weight | 13,378 kg |
| Standard Bucket Size | 1.9 m³ |
| Gross Power | 115 kW (154 hp / 156 ps) @ 2,200 rpm |
| Net Power | 106 kW (142 hp / 144 ps) @ 2,200 rpm |
| Hydraulic Cycle Time | 9.8 s |
| Raise Time | 4.8 s |
| Maximum Travel Speed, fwd | 39.8 km/h |
| Tipping load-Full Turn | 7,487 kg |
| Bucket Breakout Force | 113 kN |
| Dump Clearance at Full Height Discharge | 2,804 mm |
| Dump Reach at Full Height Discharge | 1,154 mm |
| Model | Cummins B4.5 |
| Emissions | EU Stage V |
| Aspiration | Turbocharged & Air-to-air intercooled |
| Length with Bucket Down | 7,404 mm |
| Width over Tires | 2,420 mm |
| Cab Height | 3,352 mm |
| Turning Radius, Outside of Tire | 5,213 mm |
| Bucket Capacities | 1.8-4.0 m³ |
| General Purpose | 1.9 m³ |
| Light Material | 4.0 m³ |
| Heavy Rock | / |
| Operating Weight | 12,300 kg |
| Standard Bucket Size | 2.0 m³ |
| Rated Power | 113 kW ( 152 hp / 154 ps ) @ 2,200 rpm |
| Hydraulic Cycle Time | 9.0 s |
| Raise Time | 4.8 s |
| Maximum Travel Speed, fwd | 38 km/h |
| Tipping Load-Full Turn | 8,100 kg |
| Bucket Breakout Force | 134 kN |
| Dump Clearance at Full Height Discharge | 2,956 mm |
| Dump Reach at Full Height Discharge | 1,059 mm |
| Model | Cummins QSB5.9 |
| Emissions | EPA Tier 3 / EU Stage III |
| Aspiration | Turbocharged & Air-to-air intercooled |
| Length with Bucket Down | 7,203 mm |
| Width over Tires | 2,420 mm |
| Cab Height | 3,340 mm |
| Turning Radius, Outside of Tire | 5,176 mm |
| Bucket Capacities | 1.5-3.2 m³ |
| General Purpose | 2.0 m³ |
| Light Material | 4.0 m³ |
| Heavy Rock | / |
| Operating Weight | 10,800 kg |
| Standard Bucket Size | 2.0 m³ |
| Rated Power | 103 kW ( 138 hp / 140 ps ) @ 2,200 rpm |
| Hydraulic Cycle Time | 9.7 s |
| Raise Time | 5.1 s |
| Maximum Travel Speed, fwd | 40 km/h |
| Tipping Load - Full Turn | 7,800 kg |
| Bucket Breakout Force | 100 kN |
| Dump Clearance at Full Height Discharge | 2,918 mm |
| Dump Reach at Full Height Discharge | 1,109 mm |
| Model | Yuchai YC6J140Z |
| Emissions | EPA Tier 2 / EU Stage II |
| Aspiration | Turbocharged |
| Length with Bucket Down | 7,262 mm |
| Width over Tires | 2,295 mm |
| Cab Height | 3,270 mm |
| Turning Radius, Outside of Tire | 5,113 mm |
| Bucket Capacities | 1.5-3.0 m³ |
| General Purpose | 2.0 m³ |
| Light Material | 4.0 m³ |
| Heavy-Rock | / |
