Programmable hydraulic control suitable for different applications and operating styles.
Parallel lifting function can be activated for forks or other attachments.
Customized engine is perfectly matched power-train for high efficiency and low fuel consumption.
The hydraulic system has a dual-pump confluence with steering always in priority, reducing energy loss.
Robust design of frame structure, wide spread hitch and wear-resistance bucket for maximum durability.
| Operating Weight | 15,150 kg |
| Standard Bucket Size | 2.3 m³ |
| Gross power | 126 kW (169 hp / 171 ps) @ 1,800 rpm |
| Net power | 116 kW (156 hp / 158 ps) @ 1,800 rpm |
| Hydraulic Cycle Time | 10 s |
| Raise time | 5.1 s |
| Maximum Travel Speed, fwd | 41.6 km/h |
| Tipping Load - Full Turn | 8,469 kg |
| Bucket Breakout Force | 128 kN |
| Dump Clearance at Full Height Discharge | 2,826 mm |
| Dump Reach at Full Height Discharge | 1,096 mm |
| Model | Cummins B6.7 |
| Emissions | EU Stage V |
| Aspiration | Turbocharged & Air-to-air intercooled |
| Length with Bucket Down | 7,924 mm |
| Width over Tires | 2,470 mm |
| Cab Height | 3,382 mm |
| Turning Radius, Outside of Tire | 5,395 mm |
| Bucket Capacities | 2.1-4.0 m³ |
| General Purpose | 2.3 m³ |
| Light Material | / |
| Heavy-Rock | / |
| Operating Weight | 14,000 kg |
| Standard Bucket Size | 2.3 m³ |
| Rated Power | 125 kW ( 168 hp / 170 ps ) @ 2,200 rpm |
| Hydraulic Cycle Time | 9.1 s |
| Raise Time | 4.9 s |
| Maximum Travel Speed, fwd | 39 km/h |
| Tipping Load-Full Turn | 8,800 kg |
| Bucket Breakout Force | 129 kN |
| Dump Clearance at Full Height Discharge | 2,925 mm |
| Dump Reach at Full Height Discharge | 970 mm |
| Model | Cummins QSB5.9 |
| Emissions | EPA Tier 3 / EU Stage III |
| Aspiration | Turbocharged & Air-to-air intercooled |
| Length with Bucket Down | 7,569 mm |
| Width over Tires | 2,470 mm |
| Cab Height | 3,340 mm |
| Turning Radius, Outside of Tire | 5,478 mm |
| Bucket Capacities | 2.3-4.2 m³ |
| General Purpose | 2.3 m³ |
| Light Material | / |
| Heavy Rock | / |
| Operating Weight | 14,100 kg |
| Standard Bucket Size | 2.3 m³ |
| Rated power | 129 kW ( 173 hp / 175 ps ) @ 2,200 rpm |
| Hydraulic cycle time | 9.1 s |
| Raise Time | 4.9 s |
| Maximum Travel Speed, fwd | 40.5 km/h |
| Tipping load-full turn | 8,800 kg |
| Bucket breakout force | 129 kN |
| Dump Clearance at Full Height Discharge | 2,986 mm |
| Dump Reach at Full Height Discharge | 955 mm |
| Model | Yuchai YC6J175L |
| Emissions | EPA Tier 2 / EU Stage II |
| Aspiration | Turbocharged & Air-to-air intercooled |
| Length with Bucket Down | 7,691 mm |
| Width over Tires | 2,466 mm |
| Cab Height | 3,340 mm |
| Turning Radius, Outside of Tire | 5,478 mm |
| Bucket Capacities | 2.3-4.2 m³ |
| General Purpose | 2.3 m³ |
| Light Material | / |
| Heavy-Rock | / |
