| Operating weight |
14,790 kg |
| Standard bucket |
3.0 m³ |
| Rated power |
135 kW (181 hp / 184 ps) @ 2,200 rpm |
| Maximum gross power |
128 kW (172 hp / 174 ps) @ 2,200 rpm |
| Rated load capacity |
4,000 kg |
| Hydraulic cycle time |
8.9 s |
| Raise time |
4.8 s |
| Maximum travel speed |
40 km/h |
| Tipping load-full turn |
8,500 kg |
| Bucket breakout force |
105 kN |
| Dump clearance, full height discharge |
2,660 mm |
| Dump reach, full height discharge |
1165 mm |
| Model |
Cummins QSB7 |
| Emissions |
EPA Tier 3 / EU Stage IIIA |
| Aspiration |
Turbocharged ﹠ air-to-air intercooled |
| Length with bucket down |
8,075 mm |
| Width over tires |
2,548 mm |
| Cab height |
3,310 mm |
| Turning radius, outside of tire |
5,200 mm |
| Bucket capacity |
2.5-6.0 m³ |
| General purpose bucket |
2.5 m³ |
| Light material bucket |
6.0 m³ |
| Rock bucket |
/ |
