| Operating weight | 17,900 kg |
| Standard bucket | 3.5 m³ |
| Rated power | 162 kW (217 hp / 220 ps) @ 2,200 rpm |
| Maximum gross power | 162 kW (217 hp / 220 ps) @ 2,200 rpm |
| Rated load capacity | 5,500 kg |
| Hydraulic cycle time | 9.3 s |
| Raise time | 5.8 s |
| Maximum travel speed | 38 km/h |
| Tipping load-full turn | 12,600 kg |
| Bucket breakout force | 180.7 kN |
| Dump clearance, full height discharge | 2,978 mm |
| Dump reach, full height discharge | 1,231 mm |
| Model | Cummins 6LTAA9.3 |
| Emissions | EPA Tier 2 / EU Stage II |
| Aspiration | Turbocharged ? air-to-air intercooled |
| Length with bucket down | 8,100 mm |
| Width over tires | 2,750 mm |
| Cab height | 3,500 mm |
| Turning radius, outside of tire | 6,308 mm |
| Bucket capacity | 2.7-5.6 m³ |
| General purpose bucket | 3.5 m³ |
| Light material bucket | 5.6, 6.0 m³ |
| Rock bucket | 2.7, 3.0 m³ |
| Operating weight | 18,100 kg |
| Standard bucket | 3.5 m³ |
| Rate power | 162 kW (217 hp / 220 ps) @ 2,200 rpm |
| Maximum gross power | 162 kW (217 hp / 220 ps) @ 2,200 rpm |
| Rated load capacity | 5,500 kg |
| Hydraulic cycle time | 9.4 s |
| Raise time | 5.5 s |
| Maximum travel speed | 38.6 km/h |
| Tipping load-full turn | 12,600 kg |
| Bucket breakout force | 180.7 kN |
| Dump clearance, full height discharge | 2,978 mm |
| Dump reach, full height discharge | 1,231 mm |
| Model | Cummins QSL9.3 |
| Emissions | EPA Tier 3 / EU Stage III |
| Aspiration | Turbocharged & air-to-air intercooled |
| Length with bucket down | 8,390 mm |
| Width over tires | 2,750 mm |
| Cab height | 3,500 mm |
| Turning radius, outside of tire | 6,207 mm |
| Bucket capacity | 2.7-5.6 m³ |
| General Purpose | 3.5 m³ |
| Light material | 5.6 , 6.0 m³ |
| Heavy-rock | 2.7 , 3.0 m³ |
| Operating weight | 20,150 kg |
| Standard bucket | 3.2 m³ |
| Rated power | 168 kW (225 hp / 228 ps) @ 2,000 rpm |
| Maximum gross power | 183 kW (245 hp / 248 ps) @ 1,700 rpm |
| Rated load | 5,500 kg |
| Total cycle time | 10.2 s |
| Raise time | 5.3 s |
| Maximum travel speed | 38 km/h |
| Tipping load-full turn | 13,647 kg |
| Bucket breakout force | 153 kN |
| Dump clearance, full height discharge | 2,862 mm |
| Dump reach, full height discharge | 1,207 mm |
| Model | Cummins B6.7 |
| Emissions | EU Stage V |
| Aspiration | Turbocharged & air-to-air intercooled |
| Length with bucket down | 8,303 mm |
| Width over tires | 2,750 mm |
| Cab height | 3,450 mm |
| Turning radius, outside of tire | 6,195 mm |
| Bucket capacity | 3.0-6.0 m³ |
| General purpose bucket: | 3.2 m³ |
| Light material bucket | 5.6 m³ |
| Rock bucket | 2.5, 2.7, 3.0 m³ |
