Customized engine is perfectly matched power-train for high efficiency and low fuel consumption, bringing better TCO.
Differential lock on front axle is available for better performance and reliability in slippery off-road.
Programmable hydraulic control suitable for different applications and operating styles.
Robust frame, wear-resistant bucket and dependable components make the machine work for longer.
Graphic display integrated multiple functions and parameter settings facilitates the machine to cope with various applications.
The new cab of T-series, incorporating enlarged driving space, increased legroom and wider front visibility, featuring with electric heating air suspension and ventilation seat, offers the operator a comfortable and safe driving experience.
| Operating Weight | 20,234 kg |
| Standard Bucket Size | 3.5 m³ |
| Gross Power | 183 kW (245 hp / 249 ps) @ 1,700 rpm |
| Net Power | 172 kW (231 hp / 234 ps) @ 1,700 rpm |
| Hydraulic Cycle Time | 9.6 s |
| Raise Time | 5.1 s |
| Maximum Travel Speed, fwd | 37.7 km/h |
| Tipping Load - Full Turn | 11,618 kg |
| Bucket Breakout Force | 147 kN |
| Dump Clearance at Full Height Discharge | 2,663 mm |
| Dump Reach at Full Height Discharge | 1,462 mm |
| Model | Cummins B6.7 |
| Emissions | EU Stage V |
| Aspiration | Turbocharged & Air-to-air intercooled |
| Length with Bucket Down | 8,622 mm |
| Width over Tires | 2,920 mm |
| Cab Height | 3,410 mm |
| Turning Radius, Outside of Tire | 6,304 mm |
| Bucket Capacities | 2.7-5.6 m³ |
| General Purpose | 3.5 m³ |
| Light Material | / |
| Heavy Rock | / |
| Operating Weight | 19,060 kg |
| Standard Bucket Size | 3.5 m³ |
| Rated Power | 170 kW ( 228 hp / 231 ps ) @ 2,000 rpm |
| Hydraulic Cycle Time | 9.6 s |
| Raise Time | 5.1 s |
| Maximum Travel Speed, fwd | 39 km/h |
| Tipping Load-Full Turn | 13,300 kg |
| Bucket Breakout Force | 185 kN |
| Dump Clearance at Full Height Discharge | 2,929 mm |
| Dump Reach at Full Height Discharge | 1,342 mm |
| Model | Cummins L9 |
| Emissions | EPA Tier 3 / EU Stage III |
| Aspiration | Turbocharged & Air-to-air intercooled |
| Length with Bucket Down | 8,552 mm |
| Width over Tires | 2,750 mm |
| Cab Height | 3,400 mm |
| Turning Radius, Outside of Tire | 6,260 mm |
| Bucket Capacities | 2.7-5.6 m³ |
| General Purpose | 3.5 m³ |
| Heavy Rock | / |
| Light Material | / |
