| Operating weight | 25,327 kg |
| Standard bucket | 4.5 m³ |
| Rated power | 250 kW (335 hp / 340 ps) @ 2,100 rpm |
| Maximum gross power | 272 kW (365 hp / 370 ps) @ 1,800 rpm |
| Rated load capacity | 8,000 kg |
| Hydraulic cycle time | 10.5 s |
| Raise time | 5.8 s |
| Maximum travel speed | 40 km/h |
| Tipping load-full turn | 17,560 kg |
| Bucket breakout force | 220 kN |
| Dump clearance, full height discharge | 3,305 mm |
| Dump reach, full height discharge | 1,314 mm |
| Model | Cummins L9PLUST3 |
| Emissions | EPA Tier 3 / EU Stage III |
| Aspiration | Turbocharged & air-to-air intercooled |
| Length with bucket down | 9,360 mm |
| Width over tires | 2,970 mm |
| Cab height | 3,580 mm |
| Turning radius, outside of tire | 6,625 mm |
| Bucket capacity | 3.5-8.0 m³ |
| General Purpose bucket | 4.5 m³ |
| Light material bucket | 6.0, 7.0, 8.0 m³ |
| Rock bucket | 3.5, 4.0, 4.2 m³ |
