Customized engine is perfectly matched power-train for high efficiency and low fuel consumption, bringing better TCO.
The new closed-center load-sensing hydraulic system enables simultaneous movement of the boom and bucket, resulting in higher operational efficiency.
The electronically controlled intelligent fan conserves energy, reduces noise, and features reverse rotation for self-cleaning and dust removal.
Robust design of frame structure, wide spread hitch and wear-resistance bucket for maixmum durability.
| Operating Weight | 30,360 kg |
| Standard Bucket Size | 4.5 m³ |
| Rated Power | 240 kW ( 322 hp / 326 ps ) @ 2,100 rpm |
| Hydraulic Cycle Time | 10.5 s |
| Raise Time | 5.8 s |
| Maximum Travel Speed, fwd | 37 km/h |
| Tipping Load-Full Turn | 22,300 kg |
| Bucket Breakout Force | 245 kN |
| Dump Clearance at Full Height Discharge | 3,390 mm |
| Dump Reach at Full Height Discharg | 1,237 mm |
| Model | Cummins L9 |
| Emissions | EPA Tier 3 / EU Stage III |
| Aspiration | Turbocharged & Air-to-air intercooled |
| Length with Bucket Down | 9,700 mm |
| Width over Tires | 3,152 mm |
| Cab Height | 3,760 mm |
| Turning Radius, Outside of Tire | 7,120 mm |
| Bucket Capacities | 3.5-8.0 m³ |
| General Purpose | 4.5 m³ |
| Light Material | 6.0, 7.2, 8.0 m³ |
| Heavy Rock | 5.0 m³ |
