Z-bar linkage with large transmission ratio uses high pressure hydraulics for increased breakout force.
Heavy-duty wet type brake axle and braking system ensure the reliability and durability of the product even under tough work conditions.
Fully-sealing and micro-pressuring system ensures the cab is clean and quiet. Silicone oil shock absorber reduces vibration and improves ride comfort.
Improved ergonomics for cab design with all control switches in easy reach of the operator.
| Operating Weight | 31,750 kg |
| Standard Bucket Capacity | 5.4 m³ |
| Gross Power | 287 kW (385 hp / 390 ps) @ 1,800 rpm |
| Net Power | 273 kW (366 hp / 371 ps) @ 1,800 rpm |
| Hydraulic Cycle Time | 11 s |
| Raise | 6 s |
| Maximum Travel Speed, fwd | 41.9 km/h |
| Tipping Load-Full Turn | 21,150 kg |
| Bucket Breakout Force | 270 kN |
| Dump Clearance, Full Height Discharge | 3,332 mm |
| Dump Reach, Full Height Discharge | 1,433 mm |
| Model | Cummins X12 |
| Emissions | EU Stage V |
| Aspiration | Turbocharged & Air-to-air intercooled |
| Length with Bucket Down | 9,637 mm |
| Width Over Tires | 3,170 mm |
| Cab Height | 3,790 mm |
| Turning Radius, Outside of Tire | 6,958 mm |
| Bucket Capacity | 4.0 - 9.0 m³ |
| General Purpose | 5.4 m³ |
| Light Material | 9.0 m³ |
| Heavy Rock | 5.2 m³ |
| Operating Weight | 31,560 kg |
| Standard Bucket Capacity | 5.4 m³ |
| Rated Power | 262 kW (351 hp / 356 ps) @ 2,100 rpm |
| Hydraulic Cycle Time | 11 s |
| Raise Time | 6 s |
| Maximum Travel Speed, fwd | 37 km/h |
| Tipping Load - Full Turn | 21,350 kg |
| Bucket Breakout Force | 270 kN |
| Dump Clearance at Full Height Discharge | 3,332 mm |
| Dump Reach at Full Height Discharge | 1,433 mm |
| Model | Cummins X12 |
| Emissions | EPA Tier 3 / EU Stage III |
| Aspiration | Turbocharged & Air-to-air intercooled |
| Length with Bucket Down | 9,637 mm |
| Width Over Tires | 3,170 mm |
| Cab Height | 3,790 mm |
| Turning Radius, Outside of Tire | 6,958 mm |
| Bucket Capacity | 4.0 - 9.0 m³ |
| General Purpose | 5.4 m³ |
| Light Material | 9.0 m³ |
| Heavy Rock | 5.2 m³ |
