| Operating Weight | 122,000 kg |
| Rated Power | 567 kW@ 1,800 rpm |
| Std. Bucket capacity | 8.0 m³ |
| Travel speed(High) | 3.5 km/h |
| Travel speed(Low) | 2.6 km/h |
| Maximum swing speed | 6.2 rpm |
| Arm Digging Force (ISO) | 491 kN |
| Bucket Digging Force (ISO) | 610 kN |
| Shipping Length | 14755 mm |
| Shipping Width | 5743mm |
| Shipping Height | 6364 mm |
| Track shoe width (std) | 700 mm |
| Boom | 7550 mm |
| Arm | 3400 mm |
| Max. Digging Reach | 13997 mm |
| Max. Digging Reach on Ground | 13628 mm |
| Max. Digging Depth | 8112 mm |
| Max. Vertical Wall Digging Depth | 5832 mm |
| Max. Cutting Height | 12585 mm |
| Max. Dumping Height | 8050 mm |
| Min. Front Swing Radius | 6489 mm |
| Model | Cummins QSK23 |
| Emission Regulation | Stage IIIA / CN III |
| Main Pump Total Flow | 2040 L/min |
| Relief Pressure, main | 37 MPa |
