Operating weight
|
13500 kg
|
|
Engine power
|
74 kW (99 hp / 101 ps) @ 2,200 rpm
|
|
Std. Bucket capacity
|
0.55 m3
|
|
Travel speed(High)
|
5 km/h
|
|
Travel speed(Low)
|
3.2 km/h
|
|
Maximum swing speed
|
12 rpm
|
|
Arm breakout force
|
64.9 kN
|
|
Bucket breakout force
|
89.8 kN
|
|
Shipping length
|
7750 mm
|
|
Shipping width
|
2490 mm
|
|
Shipping height
|
2930 mm |
| Track shoe width (std) | 500 mm |
| Boom | 4600 mm |
| Arm | 2500 mm |
| Digging reach | 8300 mm |
| Digging reach on ground | 8170 mm |
| Digging depth | 5470 mm |
| Vertical wall digging depth | 4770 mm |
| Cutting height | 8760 mm |
| Dumping height | 6310 mm |
| Minimum front swing radius | 2470 mm |
| Model | Cummins QSF 3.8 |
| Emission | Stage IIIA |
| System maximum flow | 2x120 L/min (2x32 gal/min) |
| System pressure | 34.3 MPa |
