| Operating weight | 14900-16400 kg |
| Engine power | 75 kW @ 2200 rpm |
| Std. Bucket capacity | 0.5 m³ |
| Travel speed(High) | 4.9 km/h |
| Travel speed(Low) | 2.9 km/h |
| Maximum swing speed | 11.3 rpm |
| Arm breakout force | 70 kN |
| Bucket breakout force | 96.9 kN |
| Shipping length | 7295 mm |
| Shipping width | 2570 mm |
| Shipping height | 3035 mm |
| Track shoe width (std) | 500 mm |
| Boom | 4600 mm |
| Arm | 2500 mm |
| Digging reach | 8315 mm |
| Digging reach on ground | 8190 mm |
| Digging depth | 5490 mm |
| Vertical wall digging depth | 5030 mm |
| Cutting height | 8960 mm |
| Dumping height | 6530 mm |
| Minimum front swing radius | 2325 mm |
| Dozer-up | 500 mm |
| Dozer-down | 575 mm |
| Engine model | Cummins F3.8 |
| Emission | Stage V / Tier4F |
| System maximum flow | 2x117 L/min |
| System pressure | 34.3 MPa |
