| Operating weight | 20,500 kg |
| Rated power | 118 kW @2,000 rpm |
| Standard Bucket Capacity | 1.0 m³ |
| Travel speed (High/Low) | 5.0 / 2.9 km/h |
| Swing speed | 10.5 rpm |
| Bucket digging force (ISO) | 135 kN |
| Arm digging force (ISO) | 105 kN |
| Shipping length | 9580 mm |
| Shipping Width | 2900 mm |
| Shipping Height | 3050 mm |
| Shoe width | 700 mm |
| Max. Digging Reach | 9770 mm |
| Max. Digging Reach on Ground | 9590 mm |
| Max. Digging Depth | 6480 mm |
| Max. Vertical Wall Digging Depth | 4600 mm |
| Max. Cutting Height | 9700 mm |
| Max. Dumping Height | 6920 mm |
| Min. Front Swing Radius | 3370 mm |
| Engine | Yuchai YCA05K160-M300 |
| Emission Regulation | CN III |
| Main Pumps Total Flow | 448 L/min |
| Relief Pressure, main | 34.3 MPa |
