| Operating weight |
22000 kg |
| Engine power |
124 kW (166 hp/168.6 ps) @ 2050 rpm |
| Bucket capacity |
1.0 m³ |
| Travel speed(High) |
5.3 km/h |
| Travel speed(Low) |
3.0 km/h |
| Maximum swing speed |
10.5 rpm |
| Arm breakout force |
97 kN |
| Arm breakout force Power boost |
105 kN |
| Bucket breakout force |
140 kN |
| Bucket breakout force Power boost |
152.5 kN |
| Shipping length |
9570 mm |
| Shipping width |
2990 mm |
| Shipping height |
3140 mm |
| Track shoe width (std) |
600 mm |
| Boom |
5710 mm |
| Arm |
2915 mm |
| Digging reach |
9870 mm |
| Digging reach on ground |
9685 mm |
| Digging depth |
6562 mm |
| Vertical wall digging depth |
5080 mm |
| Cutting height |
9945 mm |
| Dumping height |
7170 mm |
| Minimum front swing radius |
3090 mm |
| Model |
Cummins QSB7 |
| Emission |
EPA Tier 3 / EU Stage IIIA |
| System maximum flow |
2×224 L/min (2x59 gal/min) |
| System pressure |
34.3 MPa |
