| Operating Weight | 23,000 kg |
| Rated Power | 124 kw@ 2,050 rpm |
| Stadard Bucket Capacity | 1 m³ |
| Bucket Capacity | 1-1.2 m³ |
| Travel Speed (Hight/Low) | 5.3 /3.0 km/h |
| Swing Speed | 10.5 r/min |
| Bucket Digging Force(ISO) | 152.5 kN |
| Arm Digging Force(ISO) | 105 kN |
| Shipping Length | 9,620 mm |
| Shipping Width | 2,530 mm |
| Shipping Height | 3,115 mm |
| Shoe Width | 500 mm |
| Max. Digging Reach | 9,890 mm |
| Max. Digging Reach on Ground | 9,720 mm |
| Max. Digging Depth | 6,760 mm |
| Max. Vertical Wall Digging Depth | 5,140 mm |
| Max. Cutting Height | 9,750 mm |
| Max. Dumping Height | 7,030 mm |
| Engine | Cummins QSB7 |
| Emission Regulation | CN III/Stage ⅢA |
| Main Pumps Total Flow | 2×224 L/min |
| Relief Pressure, main | 34.3 MPa |
