| Operating weight | 25500 kg |
| Engine power | 133kW ( 178 hp / 181 ps) @ 2,000 rpm |
| Std. Bucket capacity | 1.2 m³ |
| Travel speed(High) | 5.8 km/h |
| Travel speed(Low) | 3.5 km/h |
| Maximum swing speed | 12 rpm |
| Arm breakout force | 124 kN |
| Arm breakout force Power boost | 134 kN |
| Bucket breakout force | 165 kN |
| Bucket breakout force Power boost | 179 kN |
| Shipping length | 10220 mm |
| Shipping width | 3190 mm |
| Shipping height | 3200 mm |
| Track shoe width (std) | 600 mm |
| Boom | 6000 mm |
| Arm | 2980 mm |
| Digging reach | 10340 mm |
| Digging reach on ground | 10150 mm |
| Digging depth | 6925 mm |
| Vertical wall digging depth | 5795 mm |
| Cutting height | 9865 mm |
| Dumping height | 6920 mm |
| Minimum front swing radius | 3695 mm |
| Model | Cummins 6BTAA5.9-C178-II |
| Emission | EPA Tier 2 / EU Stage II |
| System maximum flow | 2×240 L/min (2x63 gal/min) |
| System pressure | 34.3 MPa |
| Operating weight | 25500 kg |
| Engine power | 140 kW (188 hp / 190ps) @ 2,050 rpm |
| Std. Bucket capacity | 1.2 m³ |
| Travel speed(High) | 5.5 km/h |
| Travel speed(Low) | 3.3 km/h |
| Maximum swing speed | 10.5 rpm |
| Arm breakout force | 124 kN |
| Arm breakout force Power boost | 134 kN |
| Bucket breakout force | 165 kN |
| Bucket breakout force Power boost | 179 kN |
| Shipping length | 10220 mm |
| Shipping width | 3190 mm |
| Shipping height | 3200 mm |
| Track shoe width (std) | 600 mm |
| Boom | 6000 mm |
| Arm | 2980 mm |
| Digging reach | 10340 mm |
| Digging reach on ground | 10150 mm |
| Digging depth | 6925 mm |
| Vertical wall digging depth | 5795 mm |
| Cutting height | 9865 mm |
| Dumping height | 6920 mm |
| Minimum front swing radius | 3700 mm |
| Model | Cummins QSB7 |
| Emission | Stage IIIA |
| System maximum flow | 2×240 L/min (2x63 gal/min) |
| System pressure | 34.3 MPa |
| Operating weight | 27500 kg |
| Engine power | 133 kW ( 178 hp / 181 ps) @ 2,000 rpm |
| Std. Bucket capacity | 0.58 m³ |
| Travel speed(High) | 5.8 km/h |
| Travel speed(Low) | 3.5 km/h |
| Maximum swing speed | 12 rpm |
| Arm breakout force | 62 kN |
| Bucket breakout force | 89 kN |
| Shipping length | 12540 mm |
| Shipping width | 3390 mm |
| Shipping height | 3540 mm |
| Track shoe width (std) | 800 mm |
| Boom | 8500 mm |
| Arm | 6400 mm |
| Digging reach | 15720 mm |
| Digging reach on ground | 15620 mm |
| Digging depth | 11720 mm |
| Vertical wall digging depth | 9715 mm |
| Cutting height | 13695 mm |
| Dumping height | 11360 mm |
| Minimum front swing radius | 4848 mm |
| Model | Cummins 6BTAA5.9-C178-Ⅱ |
| Emission | Stage II / Tier 2 |
| System maximum flow | 2×240 L/min (2x63 gal/min) |
| System pressure | 34.3 MPa |
| Operating weight | 27500 kg |
| Engine power | 140 kW @ 2,050 rpm |
| Std. Bucket capacity | 0.58 m³ |
| Travel speed(High) | 5.5 km/h |
| Travel speed(Low) | 3.3 km/h |
| Maximum swing speed | 10.5 rpm |
| Arm breakout force | 62 kN |
| Bucket breakout force | 89 kN |
| Shipping length | 12540 mm |
| Shipping width | 3390 mm |
| Shipping height | 3540 mm |
| Track shoe width (std) | 800 mm |
| Boom | 8500 mm |
| Arm | 6400 mm |
| Digging reach | 15720 mm |
| Digging reach on ground | 15620 mm |
| Digging depth | 11720 mm |
| Vertical wall digging depth | 9715 mm |
| Cutting height | 13695 mm |
| Dumping height | 11360 mm |
| Minimum front swing radius | 4848 mm |
| Model | Cummins QSB7 |
| Emission | Stage IIIA |
| System maximum flow | 2×240 L/min (2x63 gal/min) |
| System pressure | 34.3 MPa |
| Operating weight | 29000 kg |
| Engine power | 140 kW (188 hp / 190 ps) @ 2,050 rpm |
| Std. Bucket capacity | 0.4 m³ |
| Travel speed(High) | 5.5 km/h |
| Travel speed(Low) | 3.3 km/h |
| Maximum swing speed | 10.5 rpm |
| Shipping length | 14625 mm |
| Shipping width | 3390 mm |
| Shipping height | 3550 mm |
| Track shoe width (std) | 800 mm |
| Boom | 10350 mm |
| Arm | 8000 mm |
| Digging reach | 18365 mm |
| Digging reach on ground | 18265 mm |
| Digging depth | 14815 mm |
| Vertical wall digging depth | 11862 mm |
| Cutting height | 14030 mm |
| Dumping height | 11925 mm |
| Minimum front swing radius | 5970 mm |
| Model | Cummins QSB7 |
| Emission | Stage IIIA |
| System maximum flow | 2×240 L/min (2x63 gal/min) |
| System pressure | 34.3 MPa |
