| Operating weight | 25500-28200 kg |
| Engine power | 116 kW (156 hp) @ 2200 rpm |
| Bucket capacity | 0.9-1.2 m³ |
| Travel speed(High) | 5.4 km/h |
| Travel speed(Low) | 3.1 km/h |
| Maximum swing speed | 10.5 rpm |
| Arm breakout force | 97/105*(Power boost) kN |
| Bucket breakout force | 140/153*(Power boost) kN |
| Shipping length | 9010 mm |
| Shipping width | 2990/3090/3190/3290 mm |
| Shipping height | 3200 mm |
| Track shoe width (std) | 600/700/800/900 mm |
| Boom | 5700 mm |
| Arm | 2915 mm |
| Digging reach | 9906 mm |
| Digging reach on ground | 9720 mm |
| Digging depth | 6530 mm |
| Vertical wall digging depth | 5100 mm |
| Cutting height | 10740 mm |
| Dumping height | 7890 mm |
| Minimum front swing radius | 2310 mm |
| Model | Cummins B6.7 |
| Emission | Stage V / Tier 4F |
| System maximum flow | 2×228 L/min |
| System pressure | 34.3 MPa |
| Operating weight | 25500-28200 kg |
| Engine power | 116 kW (156 hp) @ 2200 rpm |
| Bucket capacity | 0.9-1.2 m³ |
| Travel speed(High) | 5.4 km/h |
| Travel speed(Low) | 3.1 km/h |
| Maximum swing speed | 10.5 rpm |
| Arm breakout force | 97/105*(Power boost) kN |
| Bucket breakout force | 140/153*(Power boost) kN |
| Shipping length | 9010 mm |
| Shipping width | 2990/3090/3190/3290 mm |
| Shipping height | 3200 mm |
| Track shoe width (std) | 600/700/800/900 mm |
| Boom | 5700 mm |
| Arm | 2915 mm |
| Digging reach | 10020 mm |
| Digging reach on ground | 9830 mm |
| Digging depth | 6420 mm |
| Vertical wall digging depth | 5100 mm |
| Cutting height | 11540 mm |
| Dumping height | 8560 mm |
| Minimum front swing radius | 2210 mm |
| Model | Cummins B6.7 |
| Emission | Stage V / Tier 4F |
| System maximum flow | 2×228 L/min |
| System pressure | 34.3 MPa |
