| Operation weight |
47000-49800 kg |
| Engine power |
298 kW (400hp) @ 2100 rpm |
| Std. Bucket capacity |
3.2 m³ |
| Travel speed(High) |
5.3 km/h |
| Travel speed(Low) |
3.1 km/h |
| Maximum swing speed |
8.5 rpm |
| Arm breakout force |
268 kN |
| Arm breakout force Power boost |
287 kN |
| Bucket breakout force |
290 kN |
| Bucket breakout force Power boost |
310 kN |
| Shipping length |
11515 mm |
| Shipping width |
3340 mm |
| Shipping height |
3810 mm |
| Track shoe width (std) |
600 mm |
| Boom |
6500 mm |
| Arm |
2550 mm |
| Digging reach |
10625 mm |
| Digging reach on ground |
10388 mm |
| Digging depth |
6521 mm |
| Vertical wall digging depth |
5204 mm |
| Cutting height |
9977 mm |
| Dumping height |
7038 mm |
| Minimum front swing radius |
4645 mm |
| Model |
Cummins X12 |
| Emission |
EU Stage V/EPA Tier 4F |
| System maximum flow |
2×380 L/min (2x100 gal/min) |
| System pressure |
34.3 MPa |
