  • The 952F is powered by the latest Cummins X12 engine with a rated power of  298 kW (400 hp/405 ps) @ 2,000 rpm in compliance with EU Stage V emission standards.
  • The 952F features a tougher, reinforced heavy duty boom and arm built from high-strength tensile steel, with castings and forgings in high stress areas for heavy-duty performance and maximum uptime.
  • ROPS (Roll Over Protection System) and FOPS (Falling Object Protection System) safeguard your most important asset: your operator in the toughest environment.
  • Visibility is key to protecting your operator and workers on site. The large glass surface area, spacious cab, combined with the rear-view camera, provides an extraordinary view of the 952F’s surroundings.
  • Inspection parts, filters and water separator are conveniently located.
  • 952F
  • 952F
  • 952F
  • 952F
  • 952F

Description

Operating weight 51000 kg
Engine power 298 kW @ 2000 rpm
Bucket capacity 2.6-3.2 m³
Travel speed(High) 5.4 km/h
Maximum swing speed 8.5 rpm
Arm breakout force 265 kN
Bucket breakout force. 280 kN
Shipping length 11960 mm
Shipping height 3735 mm
Boom 6500 mm
Arm 2550 mm
Digging reach 10860 mm
Digging reach on ground 10620 mm
Digging depth 6760 mm
Vertical wall digging depth 5080 mm
Cutting height 9965 mm
Dumping height 6915 mm
Minimum front swing radius 4775 mm
Model Cummins X12
Emission EPA Tier 4F/ EU Stage V
System maximum flow 760 L/min
System pressure 34.3 MPa
