| Operating Weight | 70,500 kg |
| Engine Power | 391 kW (532hp) @ 1,800 rpm |
| Std. Bucket capacity | 4.3 m³ |
| Travel speed(High) | 4.4 km/h |
| Travel speed(Low) | 2.7 km/h |
| Maximum swing speed | 6.8 r/min |
| Arm breakout force | 319 kN |
| Arm breakout force Power boost | 347 kN |
| Bucket breakout force | 360 kN |
| Bucket breakout force Power boost | 393 kN |
| Shipping length | 12,230 mm |
| Shipping width | 4,260 mm |
| Shipping height | 4,710 mm |
| Track shoe width (std) | 650 mm |
| Boom | 6,600 mm |
| Arm | 2,900 mm |
| Digging reach | 11,450 mm |
| Digging reach on ground | 11,170 mm |
| Digging depth | 7,180 mm |
| Vertical wall digging depth | 4,070 mm |
| Cutting height | 10,950 mm |
| Dumping height | 7,030 mm |
| Minimum front swing radius | 4,900 mm |
| Model | Cummins X15 |
| Emission | CN III / Stage IIIA |
| System maximum flow | 2×450 L/min |
| System pressure | 34.3 MPa |
