| Operating Weight | 75,000-77,000 kg |
| Standard Bucket Capacity | 5 m³ |
| Engine Model | Cummins X15 |
| Emission Standard | EU Stage V |
| Rated Power (at Rated Speed) | 391 kW @ 1800 rpm |
| Net Power (at Rated Speed) | 375 kW @ 1800 rpm |
| Maximum Torque | 2373 N·m @ 1400 rpm |
| Cooling System | Water-cooled |
| Travel Speed High/Low | 4.7/3.0 km/h |
| Swing Speed | 7.51 rpm |
| Gradeability | 35 ° |
| Ground Pressure | 109.5 kPa |
| Max. Digging Force - Arm (ISO) | 331 kN |
| Max. Digging Force - Bucket (ISO) | 438 kN |
| Length (Transport Position) | 13,090 mm |
| Overall Width (Standard Track) | 4,000 / 3,360 (Variable Gauge) mm |
| Height (Transport Position) | 4,710 mm |
| Minimum Ground Clearance | 867 mm |
| Undercarriage Track Length | 5,990 mm |
| Undercarriage Track Gauge | 3350 / 2710 (Variable Gauge) mm |
| Track Width (Standard) | 650 mm |
| Max. Digging Height | 10950 mm |
| Max. Digging Reach | 12,160 mm |
| Max. Digging Depth | 7,680 mm |
| Max. Dumping Height | 7,020 mm |
| Operating Weight | 78,500 kg |
| Standard Bucket Capacity | 5.6 m³ |
| Engine Model | Cummins QSM15 77C |
| Emission Standard | EU Stage III / CN III |
| Rated Power (at Rated Speed) | 563 kW @ 1,800 rpm |
| Maximum Torque | 3,000 N·m @ 1,400 rpm |
| Cooling System | Water-cooled |
| Travel Speed High/Low | 4.7/3.0 km/h |
| Swing Speed | 6.8 r/min |
| Drawbar Pull | 495 kN |
| Gradability | 35° |
| Ground Pressure | 108 kPa |
| Max. Digging Force - Arm (ISO) | 350 kN |
| Max. Digging Force - Bucket (ISO) | 384 kN |
| Length (Transport Position) | 13,086 mm |
| Overall Width (Standard Track) | 4,252 mm |
| Height (Transport Position) | 4,961 mm |
| Minimum Ground Clearance | 917 mm |
| Undercarriage Track Length | 5,990 mm |
| Undercarriage Track Gauge | 3,350 mm |
| Track Width (Standard) | 650 mm |
| Max. Digging Reach | 12,220 mm |
| Max. Digging Reach on Ground | 11,950 mm |
| Max. Digging Depth | 7,400 mm |
| Max. Vertical Wall Digging Depth | 3,870 mm |
| Max. Cutting Height | 11,530 mm |
| Max. Dumping Height | 7,330 mm |
