| Operating Weight | 82,000 kg |
| Standard Bucket Capacity | 6.0 m³ |
| Engine Model | Cummins QSM15 |
| Emission Standard | Stage III / CN III |
| Rated Power (at Rated Speed) | 563 kW @ 2,100 rpm |
| Maximum Torque | 3,000 N·m @ 1,400 rpm |
| Cooling System | Water-cooled |
| Travel Speed High/Low | 4.4/2.6 km/h |
| Swing Speed | 6.5 r/min |
| Gradeability | 35 ° |
| Ground Pressure | 118 kPa |
| Max. Digging Force - Arm (ISO) | 376 kN |
| Max. Digging Force - Bucket (ISO) | 409 kN |
| Length (Transport Position) | 13,086 mm |
| Overall Width (Standard Track) | 4,252 mm |
| Height (Transport Position) | 4,961 mm |
| Minimum Ground Clearance | 917 mm |
| Undercarriage Track Length | 6,236 mm |
| Undercarriage Track Gauge | 3,350 mm |
| Track Width (Standard) | 650 mm |
| Max. Digging Reach | 12,220 mm |
| Max. Digging Depth | 7,400 mm |
| Max. Vertical Wall Digging Depth | 3,870 mm |
| Max. Cutting Height | 11,530 mm |
| Max. Dumping Height | 7,330 mm |
