| Operating Weight | 94,800-98,500 kg |
| Rated Power | 447.5 kW (600 hp) @ 2,100 rpm |
| Std. Bucket capacity | 7 m³ |
| Travel speed(High) | 4 km/h |
| Travel speed(Low) | 2.6 km/h |
| Maximum swing speed | 6 rpm |
| Arm Digging Force (ISO) | 364 kN |
| Bucket Digging Force (ISO) | 477 kN |
| Shipping Length | 13,887 mm |
| Shipping Width | 4,160 mm |
| Shipping Height | 5,228 mm |
| Track shoe width (std) | 650 mm |
| Boom | 7250 mm |
| Arm | 2925 mm |
| Max. Digging Reach | 12,488 mm |
| Max. Digging Reach on Ground | 12,172 mm |
| Max. Digging Depth | 7,185 mm |
| Max. Vertical Wall Digging Depth | 5,395 mm |
| Max. Cutting Height | 12,342 mm |
| Max. Dumping Height | 7,979 mm |
| Min. Front Swing Radius | 5,415 mm |
| Model | Perkins 2806J |
| Emission Regulation | Stage V |
| Main Pump Total Flow | 2 × 476 L/min |
| Relief Pressure, main | 35 MPa |
