| Operating weight | 21,300 - 23,800 kg |
|---|---|
| Bucket capacity | 0.48 - 1.44 m³ |
| Lifting capacity, along undercarriage | 9,540 kg |
| ...at reach / height | 4.0 / 1.5 m |
| Max. digging reach | 9,930 mm |
| Max. digging depth | 6,730 mm |
| Breakout force, SAE J1179 (Normal) | 123 kN |
| Breakout force, SAE J1179 (Boost) | 130 kN |
| Tear out force, SAE J1179 (Normal) | 96 kN |
| Tear out force, SAE J1179 (Boost) | 102 kN |
| Overall width | 2,990 mm |
| Tail swing radius | 2,850 mm |
