| Operating weight | 30,000 - 33,150 kg |
|---|---|
| Bucket capacity | 0.55 - 2.06 m³ |
| Lifting capacity, along undercarriage | 16,750 kg |
| ...at reach / height | 4.5 / 1.5 m |
| Max. digging reach | 10,720 mm |
| Max. digging depth | 7,350 mm |
| Breakout force, SAE J1179 (Normal) | 165 kN |
| Breakout force, SAE J1179 (Boost) | 179 kN |
| Tear out force, SAE J1179 (Normal) | 133 kN |
| Tear out force, SAE J1179 (Boost) | 144 kN |
| Overall width | 3,190 mm |
| Tail swing radius | 3,120 mm |
