| Operating weight | 27,700 - 33,100 kg |
|---|---|
| Bucket capacity | 0.52 - 2.02 m³ |
| Lifting capacity, along undercarriage | 11,020 kg |
| ...at reach / height | 6 / 1.5 m |
| Max. digging reach | 10,430 mm |
| Max. digging depth | 7,050 mm |
| Breakout force, SAE J1179 (Normal) | 164 kN |
| Breakout force, SAE J1179 (Boost) | 179 kN |
| Tear out force, SAE J1179 (Normal) | 143 kN |
| Tear out force, SAE J1179 (Boost) | 156 kN |
| Overall width | 3,190 mm |
| Tail swing radius | 3,120 mm |
