| Operating weight | 34,300 - 38,700 kg |
|---|---|
| Bucket capacity | 1 - 2.53 m³ |
| Lifting capacity, along undercarriage | 12,480 kg |
| ...at reach / height | 6 / 1.5 m |
| Max. digging reach | 11,110 mm |
| Max. digging depth | 7,480 mm |
| Breakout force, SAE J1179 (Normal) | 177 kN |
| Breakout force, SAE J1179 (Boost) | 193 kN |
| Tear out force, SAE J1179 (Normal) | 156 kN |
| Tear out force, SAE J1179 (Boost) | 170 kN |
| Overall width | 3,190 mm |
| Tail swing radius | 3,560 mm |
