| Operating weight | 36,000 - 39,120 kg |
|---|---|
| Bucket capacity | 1.6 - 2.33 m³ |
| Lifting capacity, along undercarriage | 13,960 kg |
| ...at reach / height | 6 /1.5 m |
| Max. digging reach | 11,115 mm |
| Max. digging depth | 7,485 mm |
| Breakout force, SAE J1179 (Normal) | 177 kN |
| Breakout force, SAE J1179 (Boost) | 192 kN |
| Tear out force, SAE J1179 (Normal) | 156 kN |
| Tear out force, SAE J1179 (Boost) | 170 kN |
| Overall width | 3,190 mm |
| Tail swing radius | 3,600 mm |
