EC360CN4

The EC360 is designed to deliver outstanding versatility, efficiency and productivity, making it the perfect partner for general construction projects. The EC360 features the very latest in engineering excellence, including China IV compliant D8 Volvo engine and electro-hydraulic control system. Operators can work in comfort and control thanks to a host of features designed to boost operator efficiency and performance, along with the high levels of safety and uptime synonymous with Volvo.
  • EC360CN4
  • EC360CN4
  • EC360CN4
  • EC360CN4
  • EC360CN4

Description

Operating weight 37,100 - 39,120 kg
Bucket capacity 1 - 2.53 m³
Lifting capacity, along undercarriage 10,220 kg
...at reach / height 6 / 1.5 m
Max. digging reach 10.852 mm
Max. digging depth 7,167 mm
Breakout force, SAE J1179 (Normal) 177 kN
Breakout force, SAE J1179 (Boost) 192 kN
Tear out force, SAE J1179 (Normal) 177 kN
Tear out force, SAE J1179 (Boost) 192 kN
Overall width 3,190 mm
Tail swing radius 3,585 mm
