| Operating weight | 40,200 - 45,140 kg |
|---|---|
| Bucket capacity | 1.35 - 3 m³ |
| Lifting capacity, along undercarriage | 15,930 kg |
| ...at reach / height | 6 / 1.5 m |
| Max. digging reach | 10,695 mm |
| Max. digging depth | 6,990 mm |
| Breakout force, SAE J1179 (Normal) | 198 kN |
| Breakout force, SAE J1179 (Boost) | 215 kN |
| Tear out force, SAE J1179 (Normal) | 196 kN |
| Tear out force, SAE J1179 (Boost) | 213 kN |
| Overall width | 3,340 mm |
| Tail swing radius | 3,600 mm |
