| Operating weight | 49,006 kg |
|---|---|
| Gross power | 250 kW |
| ...at engine speed | 1,500 rpm |
| Bucket capacity | 3.03 m³ |
| Lifting capacity, along undercarriage | 17,820 kg |
| ...at reach / height | 6 / 1.5 m |
| Max. digging reach | 11,817 mm |
| Max. digging depth | 7,478 mm |
| Breakout force, SAE J1179 (Normal) | 230 kN |
| Breakout force, SAE J1179 (Boost) | 251 kN |
| Tear out force, SAE J1179 (Normal) | 211 kN |
| Tear out force, SAE J1179 (Boost) | 230 kN |
| Overall width | 3,440 mm |
| Tail swing radius | 3,880 mm |
| Connector Type | Grid |
