| Operating weight | 75,200 kg |
|---|---|
| Bucket capacity | 3.3 - 5.16 m³ |
| Lifting capacity, along undercarriage | 30,760 kg |
| ...at reach / height | 6 / 1.5 m |
| Max. digging reach | 11,460 mm |
| Max. digging depth | 7,210 mm |
| Breakout force, SAE J1179 (Normal) | 323 kN |
| Breakout force, SAE J1179 (Boost) | 342 kN |
| Tear out force, SAE J1179 (Normal) | 311 kN |
| Tear out force, SAE J1179 (Boost) | 329 kN |
| Overall width | 4,285 mm |
| Tail swing radius | 4,140 mm |
