| Operating weight | 89,960 - 91,840 kg |
|---|---|
| Bucket capacity | 5.6 - 8.5 m³ |
| Lifting capacity, along undercarriage | 37,460 kg |
| ...at reach / height | 6 / 1.5 m |
| Max. digging reach | 12,270 mm |
| Max. digging depth | 7,120 mm |
| Breakout force, SAE J1179 (Normal) | 424 kN |
| Tear out force, SAE J1179 (Normal) | 408 kN |
| Overall width | 4,515 mm |
| Tail swing radius | 4,700 mm |
