| Operating weight | 14600 kg |
| Engine power | 97 kW (130 hp / 132 ps) @ 2,200 rpm |
| Std. Bucket capacity | 0.58 m³ |
| Travel Speed (High) | 30 km/h |
| Travel Speed (Low) | 7.6 km/h |
| Swing Speed | 11 rpm |
| Arm Digging Force (ISO) | 73.9 kN |
| Bucket Digging Force (ISO) | 92.8 kN |
| Shipping length | 7690 mm |
| Shipping width | 2540 mm |
| Shipping height | 3150 mm |
| Boom | 4600 mm |
| Arm | 2100 mm |
| Max. Digging Reach | 7981 mm |
| Max. Digging Reach on Ground | 7786 mm |
| Max. Digging Depth | 4912 mm |
| Max. Vertical Wall Digging Depth | 4324 mm |
| Max. Cutting Height | 8830 mm |
| Max. Dumping Height | 6346 mm |
| Min. Front Swing Radius | 2385 mm |
| Dozer-up | 500 mm |
| Dozer-down | 120 mm |
| Model | Cummins QSB 4.5 |
| Emission Regulation | Tier 3 / Stage IIIA |
| Main Pump Total Flow | 2x175 L/min (2x46 gal/min) |
| Relief Pressure, main | 34.3 MPa |
