| Operating weight | 16,595 kg |
| Standard bucket | 3 m³ |
| Rated power | 162 kW (217 hp / 220 ps) @ 2,000 rpm |
| Maximum gross power | 162 kW (217 hp / 220 ps) @ 2,000 rpm |
| Rated load capacity | 5,000 kg |
| Hydraulic cycle time | 10 s |
| Raise time | 5.8 s |
| Maximum travel speed | 37 km/h |
| Tipping load-full turn | 11,100 kg |
| Bucket breakout force | 168 kN |
| Dump clearance, full height discharge | 3,037 mm |
| Dump reach, full height discharge | 1,169 mm |
| Model | 6LT9.3 |
| Emissions | EPA Tier 2 / EU Stage II |
| Aspiration | Turbocharged ﹠ air-to-air intercooled |
| Length with bucket down | 7,923 mm |
| Width over tires | 2,750 mm |
| Cab height | 3,500 mm |
| Turning radius, outside of tire | 6,086 mm |
| Bucket capacity | 2.7-5.0 m³ |
| General Purpose bucket | 3.0 m³ |
| Light material bucket | 5.0, 5.6 m³ |
| Rock bucket: | 2.5, 2.7, 3.0 m³ |
