Name: 9035FZTS
Brand: Zhejiang Liyang Machinery Co., Ltd.
Availability: InStock
Rating: 5 (1 reviews)

Operating weight with cab	3540 kg	Operating weight with canopy	3800 kg
Engine power	18.2 kW (24.4 hp) @ 2200 rpm	Std. Bucket capacity	0.11 m³
Travel speed(High)	4.2 km/h	Travel speed(Low)	2.5 km/h
Maximum swing speed	10 rpm	Arm breakout force	20 kN
Bucket breakout force	30 kN	Shipping length	4810 mm
Shipping width	1700 mm	Shipping height	2500/2581 mm (cab/canopy)
Track shoe width (std)	300 mm	Boom	2450 mm
Arm	1320 mm	Digging reach	5385 mm
Digging reach on ground	5270 mm	Digging depth	3085 mm
Vertical wall digging depth	2503 mm	Cutting height	4710 mm
Dumping height	3310 mm	Minimum front swing radius	2416 mm
Dozer-up	370 mm	Dozer-down	390 mm
Swing boom left rotation	70°	Swing boom right rotation	50°
Model	Yanmar 3TNV88F-ESLY	Emission	Tier 4 F / Stage V
System maximum flow	99 L/min (26.2 gal/min)	System pressure	25.3 MPa
