Name: 835T
Brand: Zhejiang Liyang Machinery Co., Ltd.
Availability: InStock
Rating: 5 (1 reviews)

Customized engine is perfectly matched power-train forhigh efficiency and low fuel consumption.
ZF automatic transmission delivers smooth shift and lownoise.
Robust design of frame structure, wide spread hitch andwear-resistance bucket for maixmum durability.
T-Series new cab, ROPS/FOPS certified, pressurized andspacious interior with increased legroom, generous storagespace, panoramic visibility, ergonomically design and 12 airvents provides larger air volume for comfortable cabtemperature.
Wider access to routine maintenance points.

Operating Weight	10,300 kg	Standard Bucket Size	1.8 m³
Rated Power	113 kW (152 hp / 154 ps) @ 2,200 rpm	Hydraulic Cycle Time	9.7 s
Raise Time	5.1 s	Maximum Travel Speed, fwd	39.4 km/h
Tipping Load - Full Turn	7,121 kg	Bucket Breakout Force	113 kN
Dump Clearance at Full Height Discharge	2,996 mm	Dump Reach at Full Height Discharge	1,091 mm
Model	Cummins QSB5.9	Emissions	EPA Tier 3 / EU Stage III
Aspiration	Turbocharged & Air-to-air intercooled	Length with Bucket Down	6,947 mm
Width over Tires	2,295 mm	Cab Height	3,270 mm
Turning Radius, Outside of Tire	5,113 mm	Bucket Capacities	1.8-3.2 m³
General Purpose	1.8 m³	Light Material	/
Heavy Rock	/
